How to Build a Real-Time CDC pipeline with ScyllaDB & Redpanda

A step-by-step tutorial to capturing changed data for high-throughput, low-latency applications, using Redpanda and ScyllaDB

This blog is a guest post by Kovid Rathee. It was first published on the Redpanda blog.

CDC is a methodology for capturing change events from a source database. Once captured, the change events can be used for many downstream use cases, such as triggering events based on specific conditions, auditing, and analytics.

ScyllaDB is a distributed, wide-column NoSQL database known for its ultra-fast performance as it’s written in C++ to make the best use of the low-level Linux primitives, which helps attain much better I/O. It’s also an excellent alternative to DynamoDB as well as a popular alternative to Apache Cassandra.

ScyllaDB’s modern approach to NoSQL and its architecture supporting data-intensive and low-latency applications make it an excellent choice for many applications. ScyllaDB shines when you need it to respond and scale super fast.

Redpanda is a source available (BSL), Apache Kafka®-compatible, streaming data platform designed from the ground up to be lighter, faster, and simpler to operate. It employs a single binary architecture, free from ZooKeeper™ and JVMs, with a built-in Schema Registry and HTTP Proxy.

Since both ScyllaDB and Redpanda are purpose-built for data-intensive applications, it makes perfect sense to connect the two. This post will take you through setting up a CDC integration between ScyllaDB and Redpanda, using a Debezium CDC connector that’s compatible with Kafka Connect. Let’s dig in.

Note: Want an in-depth look at using Rust + Redpanda + ScyllaDB to build high-performance systems for real-time data streaming? Access our on-demand masterclass. You will learn how to:

  • Understand core concepts for working with event-driven architectures
  • Build a high performance streaming app with Rust
  • Avoid common mistakes that surface in real-world systems at scale
  • Evaluate the pros, cons, and best use cases for different event streaming options

How to build a real-time CDC pipeline between ScyllaDB and Redpanda

This tutorial will first guide you through the process of setting up ScyllaDB and Redpanda. You’ll create a standalone Kafka Connect cluster and incorporate the ScyllaDB CDC Connector JAR files as plugins. This will allow you to establish a connection between ScyllaDB and Kafka Connect.

This tutorial uses ScyllaDB’s CDC quickstart guide, which takes an arbitrary orders table for an e-commerce business and streams data from that to a sink using the Kafka Connect-compatible Debezium connector. The following image depicts the simplified architecture of the setup:

Connecting ScyllaDB and Redpanda using Kafka Connect

Connecting ScyllaDB and Redpanda using Kafka Connect

The orders table receives new orders and updates on previous orders. In this example, you’ll insert a few simple orders with an order_id, a customer_id, and a product. You’ll first insert a few records in the orders table and then perform a change on one of the records. All the data, including new records, changes, and deletes, will be available as change events on the Redpanda topic you’ve tied to the ScyllaDB orders table.

Prerequisites

To complete this tutorial, you’ll need the following:

Note: The operating system used in this tutorial is macOS.

1. Run and configure ScyllaDB

After installing and starting Docker Engine on your machine, execute the following Docker command to get ScyllaDB up and running:

docker run --rm -ti \
-p 127.0.0.1:9042:9042 scylladb/scylla \
--smp 1 --listen-address 0.0.0.0 \
--broadcast-rpc-address 127.0.0.1

This command will spin up a container with ScyllaDB, accessible on 127.0.0.1 on port 9042. To check ScyllaDB’s status, run the following command that uses the ScyllaDB nodetool utility:

docker exec -it 225a2369a71f nodetool status

This command should give you an output that looks something like the following:

Datacenter: datacenter1
=======================
Status=Up/Down
|/ State=Normal/Leaving/Joining/Moving
-- Address Load Tokens Owns Host ID Rack
UN 0.0.0.0 256 KB 256 ? 2597950d-9cc6-47eb-b3d6-a54076860321 rack1

The UN at the beginning of the table output means Up and Normal. These two represent the cluster’s status and state, respectively.

2. Configure CDC on ScyllaDB

To set up CDC on ScyllaDB, you first need to log in to the cluster using the cqlsh CLI. You can do that using the following command:

docker exec -it 225a2369a71f cqlsh

If you’re able to log in successfully, you’ll see the following message:

Connected to at 0.0.0.0:9042.
[cqlsh 5.0.1 | Cassandra 3.0.8 | CQL spec 3.3.1 | Native protocol v4]
Use HELP for help.
cqlsh>

Keyspaces are high-level containers for all the data in ScyllaDB. A keyspace in ScyllaDB is conceptually similar to a schema or database in MySQL. Use the following command to create a new keyspace called quickstart_keyspace with SimpleStrategy replication and a replication_factor of 1:

CREATE KEYSPACE quickstart_keyspace WITH REPLICATION = {'class': 'SimpleStrategy', 'replication_factor': 1};

Now, use this keyspace for further CQL commands:

USE quickstart_keyspace;

Please note that the SimpleStrategy replication class is not recommended for production use. Instead, you should use the NetworkTopologyStrategy replication class. You can learn more about replication methodologies from ScyllaDB University.

3. Create a table

Use the following CQL statement to create the orders table described at the beginning of the tutorial:

CREATE TABLE orders(
customer_id int,
order_id int,
product text,
PRIMARY KEY(customer_id, order_id)) WITH cdc = {'enabled': true};

This statement creates the orders table with a composite primary key consisting of customer_id and order_id. The orders table will be CDC-enabled.

ScyllaDB stores table data in a base table, but when you enable CDC on that table, an additional table that captures all the changed data is created as well. That table is called a log table.

4. Insert a few initial records

Populate a few records for testing purposes:

INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 1, 'pizza');
INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 2, 'cookies');
INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 3, 'tea');

During the course of the tutorial, you’ll insert three more records and perform an update on one record, totaling seven events in total, four of which are change events after the initial setup.

5. Set up Redpanda

Use the docker-compose.yaml file in the Redpanda Docker quickstart tutorial to run the following command:

docker compose up -d

A Redpanda cluster and a Redpanda console will be up and running after a brief wait. You can check the status of the Redpanda cluster using the following command:

docker exec -it redpanda-0 rpk cluster info

The output of the command should look something like the following:

CLUSTER
=======
redpanda.3fdc3646-9c9d-4eff-b5d6-854093a25b67

BROKERS
=======
ID HOST PORT
0* redpanda-0 9092

Before setting up an integration between ScyllaDB and Redpanda, check if all the Docker containers you have spawned are running by using the following command:

docker ps --format "table {{.Image}}\t{{.Names}}\t{{.Status}}\t{{.Ports}}"

Look for the STATUS column in the table output:

IMAGE NAMES STATUS PORTS
scylladb/scylla gifted_hertz Up 8 hours 22/tcp, 7000-7001/tcp, 9160/tcp, 9180/tcp, 10000/tcp, 127.0.0.1:9042->9042/tcp
docker.redpanda.com/vectorized/console:v2.2.4 redpanda-console Up 9 hours 0.0.0.0:8080->8080/tcp
docker.redpanda.com/redpandadata/redpanda:v23.1.8 redpanda-0 Up 9 hours 8081-8082/tcp, 0.0.0.0:18081-18082->18081-18082/tcp, 9092/tcp, 0.0.0.0:19092->19092/tcp, 0.0.0.0:19644->9644/tcp

If these containers are up and running, you can start setting up the integration.

6. Set up Kafka Connect

Download and install Kafka using the following sequence of commands:

# Extract the binaries
wget https://downloads.apache.org/kafka/3.4.0/kafka_2.13-3.4.0.tgz && tar -xzf kafka_2.13-3.4.0.tgz && cd kafka_2.13-3.4.0
#start Kafka connect in standalone mode
bin/connect-standalone.sh config/connect-standalone.properties

The .properties files will be kept in the kafka_2.13-3.4.0/config folder in your download location.

To use Kafka Connect, you must configure and validate two .properties files. You can name these files anything. In this tutorial, the two files are called connect-standalone.properties and connector.properties. The first file contains the properties for the standalone Kafka Connect instance. For this file, you will only change the default values of two variables:

  • The default value for the bootstrap.servers variable is localhost:9092. As you’re using Redpanda and its broker is running on port 19092, you’ll replace the default value with localhost:19092.
  • Find the plugin path directory for your Kafka installation and set the plugin.path variable to that path. In this case, it’s /usr/local/share/kafka/plugins. This is where your ScyllaDB CDC Connector JAR file will be copied.

The comment-stripped version of the connect-standalone.properties file should look like the following:

bootstrap.servers=localhost:19092
key.converter.schemas.enable=true
value.converter.schemas.enable=true
offset.storage.file.filename=/tmp/connect.offsets
offset.flush.interval.ms=10000
plugin.path=/usr/local/share/kafka/plugins

The second .properties file will contain settings specific to the ScyllaDB connector. You need to change the scylla.cluster.ip.addresses variable to 127.0.0.1:9042. The connector.properties file should then look like the following:

name = QuickstartConnector
connector.class = com.scylladb.cdc.debezium.connector.ScyllaConnector
key.converter = org.apache.kafka.connect.json.JsonConverter
value.converter = org.apache.kafka.connect.json.JsonConverter
scylla.cluster.ip.addresses = 127.0.0.1:9042
scylla.name = QuickstartConnectorNamespace
scylla.table.names = quickstart_keyspace.orders

Using both the .properties files, go to the Kafka installation directory and run the connect-standalone.sh script with the following command:

bin/connect-standalone.sh config/connect-standalone.properties config/connector.properties

When you created the orders table, you enabled CDC, which means that there’s a log table with all the records and changes. If the Kafka Connect setup is successful, you should now be able to consume these events using the rpk CLI tool. To do so, use the following command:

rpk topic consume --brokers 'localhost:19092' QuickstartConnectorNamespace.quickstart_keyspace.orders | jq .

The output should result in the following three records, as shown below:

{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":1}}",
"value":
…output omitted…
"timestamp": 1683357426891,
"partition": 0,
"offset": 0
}
{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":2}}",
"value":
…output omitted…
"timestamp": 1683357426898,
"partition": 0,
"offset": 1
}
{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":3}}",
"value":
…output omitted…
"timestamp": 1683357426898,
"partition": 0,
"offset": 2
}

If you get a similar output, you’ve successfully integrated ScyllaDB with Redpanda using Kafka Connect. Alternatively, you can go to the Redpanda console hosted on localhost:8080 and see if the topic corresponding to the ScyllaDB orders table is available:

A working connection between ScyllaDB and Redpanda on the Redpanda console

You can now test whether data changes to the orders table can trigger CDC.

7. Capture Change Data (CDC) from ScyllaDB

To test CDC for new records, insert the following two records in the orders table using the cqlsh CLI:

INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 4, 'chips');
INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 5, 'lollies');

If the insert is successful, the rpk topic consume command will give you the following additional records:

{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":4}}",
"value":
…output omitted…
"timestamp": 1683357768358,
"partition": 0,
"offset": 3
}
{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":5}}",
"value":
…output omitted…
"timestamp": 1683358068355,
"partition": 0,
"offset": 4
}

You’ll now insert one more record with the product value of pasta:

INSERT INTO quickstart_keyspace.orders(customer_id, order_id, product) VALUES (1, 5, 'pasta');

Later on, you’ll change this value with an UPDATE statement to spaghetti and trigger a CDC update event.

The newly inserted record should be visible with your rpk topic consume command:

{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":6}}",
"value":
…output omitted…
"timestamp": 1683361158363,
"partition": 0,
"offset": 5
}

Now, execute the following UPDATE statement and see if a CDC update event is triggered:

UPDATE quickstart_keyspace.orders SET product = 'spaghetti' WHERE order_id = 6 and customer_id = 1;

After running this command, you’ll need to run the rpk topic consume command to verify the latest addition to the QuickstartConnectorNamespace.quickstart_keyspace.orders topic. The change event record should look like the following:

{
"topic": "QuickstartConnectorNamespace.quickstart_keyspace.orders",
"key": "{\"schema\":{\"type\":\"struct\",\"fields\":[{\"type\":\"int32\",\"optional\":true,\"field\":\"customer_id\"},{\"type\":\"int32\",\"optional\":true,\"field\":\"order_id\"}],\"optional\":false,\"name\":\"QuickstartConnectorNamespace.quickstart_keyspace.orders.Key\"},\"payload\":{\"customer_id\":1,\"order_id\":6}}",
"value":
…output omitted…
"timestamp": 1683362868372,
"partition": 0,
"offset": 6
}

8. Access the captured data using Redpanda Console

When you spin up Redpanda using Docker Compose, it creates a Redpanda cluster and a Redpanda Console. Using the console, you can visually inspect topics and messages. After all the change events on the orders table are captured, you can go to the Redpanda Console and select the QuickstartConnectorNamespace.quickstart_keyspace.orders topic to see the messages, as shown below:

Redpanda console showing all events in the topic

Redpanda console showing all events in the topic

You can also see the schema details, the payload, and other event metadata in the event message, as shown below:

Redpanda console showing details of one of the events

Redpanda Console showing details of one of the events

You’ve now successfully set up CDC between ScyllaDB and Redpanda, consumed change events from the CLI, and accessed the same messages using the Redpanda Console!

Conclusion

This tutorial introduced you to ScyllaDB and provided step-by-step instructions to set up a connection between ScyllaDB and Redpanda for capturing changed data. Messaging between systems is one of the most prominent ways to create asynchronous, decoupled applications. Bringing CDC events to Redpanda allows you to integrate various systems.

Using this CDC connection, you can consume data from Redpanda for various purposes, such as triggering workflows based on change events, integrating with other data sources, and creating a data lake. By following the tutorial and using the supporting GitHub repository, you can easily get started with CDC.

To explore Redpanda, check the documentation and browse the Redpanda blog for more tutorials. If you have any questions or want to chat with the team, join the Redpanda Community on Slack.

Likewise, if you want to learn more about ScyllaDB, see our documentation, visit ScyllaDB University (free), and feel free to reach out to the team.
